NX Electrode Design

The automation of electrode design and management

NX Electrode Design supports and optimises the modelling of electrodes in all tool projects. The module helps you to manage highly complex electrodes and to automate the design and manufacturing process.

At this point, external content is loaded by www.youtube-nocookie.com. If you agree to the use of cookies, you no longer need to manually accept access to this content.
Click here to confirm the cookie settings again.

Your advantages at a glance

  • Shortened design time from the finished part to the electrode
  • Data container for EDM process, manufacturing cell
  • Interface for the subsequent processes
  • Illustration, management of standard blanks and holders
  • Details adjustable to suit customer situation

Technical facts at a glance

  • Design of the working area of the electrode and clearances
  • Negative measurements for electrodes
  • Inspection of electrodes
  • Recognition of the manufacturing geometry
  • Creation of documentation and part lists

Benefit from JANUS expertise

We are on hand as experts to support you in the automation of your tool projects. We are familiar with the capabilities of the system and its modules. You are familiar with the capabilities and needs of your company and its tool projects. Together we will find the best method for the automation of your electrode design.
